Huawei 10GE SFP+ Optical Modules
02310JFE
Item | Description |
|---|---|
Part number | 02310JFE |
Version support | Supported only in V100R001C00 and V100R002C00 |
Transceiver form factor | SFP+ |
Transmission speed | 10G |
Center wavelength (nm) | 1550 |
Standards compliance | 10GBASE-ZR |
Connector type | LC |
Type of the end face of the fiber ceramic ferrule | PC or UPC |
Applicable cable and maximum transmission distance | Single-mode fiber (G.652) (with diameter of 9 μm): 80 km |
Modal bandwidth | - |
Transmit power (dBm) | 0 to 4 |
Maximum receiver sensitivity (dBm) | -24 |
Overload power (dBm) | -7 |
Extinction ratio (dB) | ≥ 9 |
Operating temperature | 0°C to 70°C |
